Expected dimensional tolerance
+/- 0.40 mm for most features up to 100 mm, then approximately +/- 0.75% beyond that. Tight mating features may still need post-fit adjustment.
Minimum recommended wall
1.2 mm minimum. For stronger parts or long thin walls, 1.8 mm or more is preferred.
Minimum recommended detail
Raised or recessed details should be at least 0.8 mm deep or high and about 1.2 mm wide for clean reproduction.
Surface finish
Layer lines will be visible at 0.24 mm. Curved faces and shallow slopes will show a typical FDM stepped finish.
Holes and slots
Small holes often print undersize. For functional holes, add clearance or plan to drill or ream after printing if fit is critical.
Flatness and long overhangs
Large flat parts can warp slightly depending on geometry and material. Unsupported overhangs may trigger a support recommendation during quoting.
